BY26 Fish Shape Mask Making Machine 1+1
Major Parameter：
Power Supply：220V
Output power：10KW
Weight：1200KG
Capacity：40-60 pcs/min
Dimensions：5.4*1.9*1.7 meter
Final products：
Configuration list:
| Model Name | Brand | Quantity | Place of Origin |
| Ultrasonic System | Yachao | 15K two sets 20K two sets | China |
| Servo Motor | Taida | 1 | Taiwan, China |
| Stepper Motor | Zhili | 1 | China |
| PLC | Zhili | 2 | China |
Touch screen | Xinjie | 2 | China |
| three-phrase electric machine | Jindun | 1 | China |
| constant-speed electric machine | Zhongda | 3 | China |
| Adjustable-speed Motor | Zhongda | 1 | China |
| Transducer | Zezan | N | China |
| Solenoid Valve | Ruixong | N | China |
| Air cylinder | Adak | N | China |
| Bearing | JY | N | China |
List of Major Mechanical Components
| Name | Service Life（Year） | Material | Notes |
| Material Shelf | 20 | Aluminium product | |
| Hand expanding shaft | 5 | Aluminium、Stainless steel | |
| Track and drilling crew table | 20 | Aluminium product、Stainless steel | |
| Nose strip kit | 10 | Chromiun-plated steel | Complete set 10 years, cutter is half a year, pressing wheel 2 years |
| Rack Mould | 3 | special steel, hardening by heat treatment | |
| nose strip tray | 20 | Stainless steel | |
| cutter | 0.5 | special steel, hardening by heat treatment | |
| Bearing | 3 | standard parts | |
| wheel gear | 3 | standard parts | |
| chain | 3 | standard parts | |
| charging tray | 20 | the anode aluminium | |
| ultrasonic welding | 3 | Steel mould，hardness 45 | |
| Earloop structural component | 10 | Chromium-plated steel, Aluminium，belt | Cutter is quick-wearing parts |
| Discharge hole | 20 | Air cylinder and belts are wearing parts | |
| Finished product conveyor belt | 5 | Aluminium，belt | Belts belong to wearing parts |
Quick-wear part list（Random gift）
| Name | Quantity | |
| Nose strip cutter | 1 | |
| ear loop cutter | 2 | |
| belts | 11 | |
| Protective tube | N | |
| Bubble cotton | N |
Guarantee clause：
Warranty: the whole machine is guaranteed for one year, except for ultrasonic and wearing parts
On-site installation and debugging：only operations by video during epidemic situation, domestic technicist can be sent to the factory for free training.
Raw material：
1. non-woven fabric： 15-30g，white, blue and pink
2. Melt-blown fabric：20-50g，BEF<=99%
3. bright of nose：single or double core 2.0-3.0*0.3MM，or plastic
4. Ear loop：round ear loop，diameter 2.0-3.0
Installation Instruction：
Packing:
A set of machine have three wooden box packing:
1. Wooden box size of flat body mask making machine: 2080*890*1780MM
2. Wooden box size of ear loop welding machine:1590*1060*1520MM
3. Cloth stall 1750*840*1580MM
